Simgasm Universal Seat Mount

Name: Simgasm Universal Seat Mount
Brand: SIMGASM
SKU: SG-SB
Price: 178.05 PLN
Availability: OutOfStock

Reference SG-SB

178.05zł

The Simgasm Universal Seat Mount contains two supports made from 4 mm steel for fixed-back bucket seats with side mounting points. Multiple holes allow the seat height and angle to be adjusted around the driver, pedals and steering wheel. The brackets are required for the SIMGASM Atlas seat range and also fit many other side-mounted bucket seats.

Ask about product

You will receive an 1.78zł for each item of this product to use on your next purchase.

Shipping within 24 hours

Secure payments

Return within 30 days

Delivery from PLN 0

A rigid connection between seat and cockpit

The Simgasm Universal Seat Mount connects a fixed-back bucket seat to the cockpit structure. Two supports hold the seat on its left and right sides, creating a stable reference point for the driver's entire position. Reducing unwanted seat movement matters under heavy braking, during quick steering corrections and throughout longer runs where body position should remain repeatable from one input to the next.

The brackets do not replace a correct connection to the cockpit base, seat slider or aluminium profiles. Tighten each point evenly and inspect the installation again after the first sessions. The best result comes from treating the seat, brackets, pedals and steering wheel as one system: even a rigid seat will not improve ergonomics when it sits too high, too far from the pedals or at an unsuitable angle.

Height and angle adjustment without changing the seat

The extensive hole pattern along the upright sections allows the seat height and inclination to be changed. A driver can begin with a more upright GT position, then lower the rear or raise the front when the cockpit geometry calls for a more reclined layout. This adjustment helps align thigh support, hip position and leg reach without drilling or modifying the seat shell.

Make changes gradually and keep the left and right sides symmetrical. Set height first, adjust the angle next and finish by checking the distance to the pedals and steering wheel. After every change, test full brake travel, free knee movement and a slight bend at the elbows. This order makes it easier to build a position that remains comfortable well beyond the first few laps.

Four-millimetre steel for regular simulator use

SIMGASM makes the bracket set from 4 mm steel. The construction is intended to provide rigid seat support in regularly used simulator setups, including situations that involve decisive pedal inputs. Its black finish integrates naturally with dark cockpit profiles, sliders and bucket-seat shells, while the durable coating helps the mounting area retain a clean, purposeful appearance.

The official product page does not state the coating process, bracket-set weight or maximum load, so these values should not be replaced with estimates. Actual system capacity also depends on the seat, slider, cockpit base and fasteners. Before driving, confirm that the components are not tightened under unwanted stress and that bolt heads and washers do not interfere with adjustment or contact the seat shell.

Pair of black SIMGASM side-mount seat brackets with adjustment holes

A rigid connection between seat and cockpit

| SIMGASM seat mount showing multi-level height and angle adjustment

Height and angle adjustment without changing the seat

| Side view of SIMGASM bucket-seat brackets showing the adjustment range

Four-millimetre steel for regular simulator use

Designed for side-mounted fixed-back bucket seats

The bracket set was developed for the SIMGASM Atlas family and is identified by the manufacturer as a required mounting component for those seats. It also supports many other fixed-back bucket seats with side attachment points. Before selecting another model, compare its hole pattern, shell width and bolt access. Current options can be reviewed in the sim racing seats category at Simline.eu.

These brackets are not required for reclining seats, which typically use mounting points beneath the seat base. The SIMGASM Core Recline Seat is one example. A compatible base or slider is still needed on the cockpit side, so review the frame under sim racing cockpits and confirm the complete connection path from profile to seat before installation.

Parameter	Value
Manufacturer	SIMGASM
Model name	Simgasm Universal Seat Mount
Product reference	SG-SB
Manufacturer SKU	SB
Product type	Side-mount bracket set for a fixed-back bucket seat
Number of brackets	2 – left and right
Material	Steel
Material thickness	4 mm
Colour	Black
Finish	Durable black coating; process not published
Adjustment	Seat height and angle
Intended seat type	Fixed-back bucket seats with side mounting points
Dedicated seat family	SIMGASM Atlas
Reclining seats	The bracket set is not required or intended for this configuration
Dimensions	Not published by the manufacturer
Hole spacing	Not published by the manufacturer
Net weight	Not published by the manufacturer
Maximum load	Not published by the manufacturer
Bolts and washers	No confirmed list on the manufacturer page
Seat and slider	Sold separately

1. What is the Simgasm Universal Seat Mount for?

It connects a fixed-back bucket seat to a cockpit base and allows the seat height and angle to be adjusted.

2. What is included in the set?

The product consists of left and right side brackets. The official page does not publish a complete list of bolts, washers or intermediate mounting parts.

3. What are the brackets made from?

They are made from 4 mm steel and finished with a durable black coating. SIMGASM does not state the coating process.

4. Which seat settings can be adjusted?

The hole pattern allows height and angle adjustment. The final range also depends on the seat shell, slider and cockpit base.

5. Does the bracket set fit SIMGASM Atlas seats?

Yes. It was developed for the Atlas family and is identified by SIMGASM as a required mounting component for these seats.

6. Does it fit every bucket seat?

Universal fit should not be assumed. The seat needs side mounting points, and its hole spacing, width and bolt access must be compared before purchase.

7. Are these brackets required for a reclining seat?

No. The set is intended for fixed-back bucket seats and is not required for reclining designs such as the SIMGASM Core.

8. Is a seat slider necessary?

Not always. A fixed installation can use the brackets with a compatible base, while a slider adds convenient fore-and-aft adjustment.

9. What is the maximum load?

SIMGASM does not publish a maximum load. Safe use also depends on the seat, fasteners, slider and cockpit structure.

10. How should the seat be set after installation?

Adjust both sides symmetrically, test full pedal travel and keep a slight bend in the knees and elbows. Tighten every connection and inspect it again after the first sessions.
